Vapor Intrusion Monitoring
A new tool for vapor intrusion
and soil gas investigations
AirLogics new field Gas Chromatograph (GC) features:
-
Rapid, real-time data collection of potentially up to 100 of sample/day
-
Lightweight and portable
-
Reliable and accurate field screening tool for Volatile Organic Compounds (VOCs), including chlorinated solvents and BTEX
How it works:
-
1.AirLogics provides the field GC and a technician to assist your team collect the samples.
-
2.Real-time data provided in-field via tablet
-
GC equipped with 5-hour on board battery, or can run from 110-line power
if available at the site.
Background on the System
In 2022, AirLogics installed a brand new state-of-the-art field gas chromatograph into their upgraded Classic 2.0 perimeter air monitoring system. Through the development of the Classic 2.0 system, AirLogics realized the flexibility and practicality of this new GC - and are now making it available to consultants for field vapor intrusion screening applications.
Gas Chromatograph
COMPACT SIZE
The NovaTest P100 is only 36 x 30 x 15 cm and 7 kg, but it integrates the auto-sampling unit, carrier gas system, separation unit, detection unit and a rechargeable battery within a single system.
CONVENIENT ACCESSORIES
The sampling needle, disposable filters and sampling tube are provided for versatile on-site sampling approaches, and a carrying case for the P100 and all the accessories further improves the mobility.
Outstanding Performance
GOOD RESOLUTION
The NovaTest P100 adopts microfluidic design and the patented NovaPID with MEMS technology. It has nearly zero system dead volume, giving sharp peaks regardless of sampling concentration and good peak shape with less tailing.
REPRODUCIBLE
Great reproducibility with RSD of retention time less than 1 % and RSD of peak area less than 25 % (under same testing environment), complying with most EPA recommended GC methods;
300+ THEORETICALLY DETECTABLE COMPOUNDS
The 10.6 eV NovaPID detects both inorganic and organic compounds. It is capable of detecting 300+ compounds theoretically without consuming them.
2 DETECTION RANGE OPTIONS
The NovaTest P100 has 2 models for either trace detection from 1 ppb to 1 ppm or higher concentration detection from 200 ppb to 200 ppm.
External Compatibility
Sampling From A Container
The sampling needle is can be attached to the sampling port of the NovaTest P100 when sampling from a container like a sampling bag or a canister.
Filtering Dirty Samples
The PTFE filters are used to filter the dust or large particles in the air samples.
Sampling From A Gas Line
The PTFE connection tube can be attached to the sampling port of the NovaTest P100 when the sample comes from a gas line.
Air Quality Analysis
19 targeted compounds in TO-14 chemical standard:
TO-14 calibration mix standard Chemical concentration: approx. 50 ppb each Sampling time: 0.5 min
Method used: Air Quality
